Hydrogen purification is a critical process in industries that require ultra-high purity hydrogen gas. Contaminants such as moisture, oxygen, nitrogen, and hydrocarbons can negatively impact performance in applications like fuel cells, semiconductor manufacturing, and chemical processing. Our hydrogen purifiers utilize advanced purification technologies to ensure clean, high-quality hydrogen.
Importance of Hydrogen Purification
Impurities in hydrogen gas can cause:
• Reduced Efficiency in Fuel Cells
• Contamination in Semiconductor Manufacturing
• Catalyst Poisoning in Chemical Processes
• Safety Hazards Due to Unwanted Reactions
• Decreased Equipment Lifespan & beverage.
How Hydrogen Purifiers Work
Hydrogen purification systems employ different methods to remove contaminants:
• Adsorption Technology: Uses materials like molecular sieves and activated carbon to capture impurities.
• Catalytic Purification: Eliminates oxygen and other reactive impurities using catalytic conversion.
• Membrane Separation: Selectively filters hydrogen molecules from contaminants.
• Cryogenic Purification: Lowers temperature to condense and remove unwanted gases.
Key Features:
• Ultra-High Purity Hydrogen (Up to 99.9999%).
• Efficient Impurity Removal (Moisture, Oxygen, Nitrogen, CO, CO2, and Hydrocarbons).
• Energy-Efficient and Cost-Effective Operation.
• Compact and Modular Design for Easy Integration.
• Low Maintenance Requirements with Long Service Life.
Technical Specifications:
• Operating Pressure: Up to 45 bar
• Inlet Temperature: Up to 80°C
• Ambient Temperature: 1.5 to 50°C
• Voltage & Frequency: 400 V, 50 Hz
• Protection Class (Controller): IP 65
• Communication Protocols: Modbus TCP/IP, Profinet TCP/IP (others available upon request)
• Inlet Filter Requirement: Super fine coalescing
• Outlet Filter Requirement: Dust filter; 1?m
• Column Insulation: Yes
• Valve Position Switches: Yes
• Certification: CE/ATEX (IECEx available upon request)
Model Capacities:
| Model |
Capacity (m3/h) |
Capacity (kg/h) |
Electrolyser (MW) |
|---|---|---|---|
| H2-PURE 15 | 52.5 | 4.3 | 0.25 |
| H2-PURE 30 | 105 | 8.7 | 0.5 |
| H2-PURE 60 | 210 | 17.4 | 1 |
| H2-PURE 300 | 1,050 | 86.8 | 5 |
| H2-PURE 600 | 2,100 | 173.7 | 10 |
| H2-PURE 1200 | 4,200 | 347.3 | 20 |
| H2-PURE 2500 | 8,400 | 694.7 | 40 |
| H2-PURE 3600 | 12,600 | 1,042.0 | 60 |
| H2-PURE 5000 | 16,800 | 1,389.4 | 80 |
| H2-PURE 6500 | 21,000 | 1,736.7 | 100 |
Applications:
• Fuel Cells: Provides ultra-pure hydrogen for efficient energy conversion.
• Semiconductor Industry: Prevents contamination in microelectronics production.
• Petrochemical & Refining: Ensures hydrogen purity for catalytic processes.
• Aerospace & Defense: Supports high-purity hydrogen needs in propulsion and testing.
• Pharmaceutical & Medical: Supplies clean hydrogen for laboratory and medical applications.
Why Use Hydrogen Purifiers?
• Ensures High-Purity Hydrogen for Critical Applications
• Reduces Contaminant Levels to Meet Industry Standards
• Increases Efficiency in Fuel Cells and Industrial Processes
• Extends Equipment Life by Preventing Corrosion and Damage
• Supports Compliance with Stringent Purity Regulations
